Lexan PC 500ECR Physical property
|
10 ％玻璃纖維填充,注射模壓級,非氯化非溴化阻燃UL - 94 V0(2.3mm),它有各種不透明的顏色. |
|
Property |
| TYPICAL PROPERTIES (1) | ||||
|
MECHANICAL |
Value | Unit | Standard | |
|
Tensile Stress, yld, Type I, 5 mm/min |
580 |
kgf/cm2 |
ASTM D 638 | |
|
Tensile Stress, brk, Type I, 5 mm/min |
480 |
kgf/cm2 |
ASTM D 638 | |
|
Tensile Strain, yld, Type I, 5 mm/min |
4.7 |
% |
ASTM D 638 | |
|
Tensile Strain, brk, Type I, 5 mm/min |
46 |
% |
ASTM D 638 | |
|
Tensile Modulus, 5 mm/min |
25000 |
kgf/cm2 |
ASTM D 638 | |
|
Flexural Stress, brk, 1.3 mm/min, 50 mm span |
950 |
kgf/cm2 |
ASTM D 790 | |
|
Flexural Modulus, 1.3 mm/min, 50 mm span |
31800 |
kgf/cm2 |
ASTM D 790 | |
|
Taber Abrasion, CS-17, 1 kg |
11 |
mg/1000cy |
SABIC Method | |
|
Tensile Stress, yield, 5 mm/min |
60 |
MPa |
ISO 527 | |
|
Tensile Stress, break, 5 mm/min |
45 |
MPa |
ISO 527 | |
|
Tensile Strain, yield, 5 mm/min |
5 |
% |
ISO 527 | |
|
Tensile Strain, break, 5 mm/min |
7 |
% |
ISO 527 | |
|
Tensile Modulus, 1 mm/min |
3300 |
MPa |
ISO 527 | |
|
Flexural Stress, yield, 2 mm/min |
95 |
MPa |
ISO 178 | |
|
Flexural Modulus, 2 mm/min |
3400 |
MPa |
ISO 178 | |
|
Hardness, H358/30 |
115 |
MPa |
ISO 2039-1 | |
|
IMPACT |
Value | Unit | Standard | |
|
Izod Impact, unnotched, 23°C, 6.4mm |
NB |
cm-kgf/cm |
ASTM D 4812 | |
|
Izod Impact, notched, 23°C |
13 |
cm-kgf/cm |
ASTM D 256 | |
|
Izod Impact, notched, -30°C |
10 |
cm-kgf/cm |
ASTM D 256 | |
|
Instrumented Impact Total Energy, 23°C |
622 |
cm-kgf |
ASTM D 3763 | |
|
Izod Impact, unnotched 80*10*3 +23°C |
NB |
kJ/m2 |
ISO 180/1U | |
|
Izod Impact, unnotched 80*10*3 -30°C |
130 |
kJ/m2 |
ISO 180/1U | |
|
Izod Impact, notched 80*10*3 +23°C |
10 |
kJ/m2 |
ISO 180/1A | |
|
Izod Impact, notched 80*10*3 -30°C |
8 |
kJ/m2 |
ISO 180/1A | |
|
Izod Impact, unnotched 80*10*4 +23°C |
NB |
kJ/m2 |
ISO 180/1U | |
|
Izod Impact, unnotched 80*10*4 -30°C |
NB |
kJ/m2 |
ISO 180/1U | |
|
Charpy 23°C, V-notch Edgew 80*10*3 sp=62mm |
10 |
kJ/m2 |
ISO 179/1eA | |
|
Charpy -30°C, V-notch Edgew 80*10*3 sp=62mm |
9 |
kJ/m2 |
ISO 179/1eA | |
|
Charpy 23°C, Unnotch Edgew 80*10*3 sp=62mm |
NB |
kJ/m2 |
ISO 179/1eU | |
|
Charpy -30°C, Unnotch Edgew 80*10*3 sp=62mm |
NB |
kJ/m2 |
ISO 179/1eU | |
|
Charpy 23°C, V-notch Edgew 80*10*4 sp=62mm |
9 |
kJ/m2 |
ISO 179/1eA | |
|
Charpy Impact, notched, 23°C |
15 |
kJ/m2 |
ISO 179/2C | |
|
Charpy 23°C, Unnotch Edgew 80*10*4 sp=62mm |
NB |
kJ/m2 |
ISO 179/1eU | |
|
Charpy -30°C, Unnotch Edgew 80*10*4 sp=62mm |
NB |
kJ/m2 |
ISO 179/1eU | |
|
THERMAL |
Value | Unit | Standard | |
|
Vicat Softening Temp, Rate B/50 |
154 |
°C |
ASTM D 1525 | |
|
HDT, 0.45 MPa, 3.2 mm, unannealed |
143 |
°C |
ASTM D 648 | |
|
HDT, 1.82 MPa, 3.2mm, unannealed |
136 |
°C |
ASTM D 648 | |
|
CTE, -40°C to 40°C, flow |
4.68E-05 |
1/°C |
ASTM E 831 | |
|
CTE, -40°C to 40°C, xflow |
8.46E-05 |
1/°C |
ASTM E 831 | |
|
Thermal Conductivity |
0.21 |
W/m-°C |
ISO 8302 | |
|
CTE, -40°C to 40°C, xflow |
8.46E-05 |
1/°C |
ISO 11359-2 | |
|
CTE, 23°C to 80°C, flow |
4.E-05 |
1/°C |
ISO 11359-2 | |
|
Ball Pressure Test, 125°C +/- 2°C |
PASSES |
- |
IEC 60695-10-2 | |
|
Vicat Softening Temp, Rate B/50 |
141 |
°C |
ISO 306 | |
|
Vicat Softening Temp, Rate B/120 |
143 |
°C |
ISO 306 | |
|
HDT/Be, 0.45MPa Edgew 120*10*4 sp=100mm |
144 |
°C |
ISO 75/Be | |
|
HDT/Ae, 1.8 MPa Edgew 120*10*4 sp=100mm |
136 |
°C |
ISO 75/Ae | |
|
HDT/Af, 1.8 MPa Flatw 80*10*4 sp=64mm |
136 |
°C |
ISO 75/Af | |
|
HDT/Ae, 1.8 MPa Annealed 120°C, 2hrs |
142 |
°C |
ISO 75/Ae | |
|
Relative Temp Index, Elec |
130 |
°C |
UL 746B | |
|
Relative Temp Index, Mech w/impact |
130 |
°C |
UL 746B | |
|
Relative Temp Index, Mech w/o impact |
130 |
°C |
UL 746B | |
|
PHYSICAL |
Value | Unit | Standard | |
|
Specific Gravity |
1.27 |
- |
ASTM D 792 | |
|
Mold Shrinkage, flow, 3.2 mm |
0.4 - 0.6 |
% |
SABIC Method | |
|
Mold Shrinkage, xflow, 3.2 mm |
0.4 - 0.6 |
% |
SABIC Method | |
|
Melt Flow Rate, 300°C/1.2 kgf |
7.5 |
g/10 min |
ASTM D 1238 | |
|
Density |
1.25 |
g/cm2 |
ISO 1183 | |
|
Water Absorption, (23°C/sat) |
0.31 |
% |
ISO 62 | |
|
Moisture Absorption (23°C / 50% RH) |
0.13 |
% |
ISO 62 | |
|
Melt Volume Rate, MVR at 300°C/1.2 kg |
7 |
cm210 min |
ISO 1133 | |
|
ELECTRICAL |
Value | Unit | Standard | |
|
Hot Wire Ignition {PLC) |
4 |
PLC Code |
UL 746A | |
|
High Ampere Arc Ign, surface {PLC} |
4 |
PLC Code |
UL 746A | |
|
Comparative Tracking Index (UL) {PLC} |
3 |
PLC Code |
UL 746A | |
|
Volume Resistivity |
>1.E+15 |
Ohm-cm |
IEC 60093 | |
|
Surface Resistivity, ROA |
>1.E+15 |
Ohm |
IEC 60093 | |
|
Dielectric Strength, in oil, 0.8 mm |
33 |
kV/mm |
IEC 60243-1 | |
|
Dielectric Strength, in oil, 1.6 mm |
25 |
kV/mm |
IEC 60243-1 | |
|
Dielectric Strength, in oil, 3.2 mm |
16 |
kV/mm |
IEC 60243-1 | |
|
Relative Permittivity, 50/60 Hz |
2.9 |
- |
IEC 60250 | |
|
Relative Permittivity, 1 MHz |
2.8 |
- |
IEC 60250 | |
|
Dissipation Factor, 50/60 Hz |
0.001 |
- |
IEC 60250 | |
|
Dissipation Factor, 1 MHz |
0.01 |
- |
IEC 60250 | |
|
Comparative Tracking Index |
150 |
V |
IEC 60112 | |
|
FLAME CHARACTERISTICS |
Value | Unit | Standard | |
|
UL Recognized, 94V-1 Flame Class Rating (3) |
1.8 |
mm |
UL 94 | |
|
UL Recognized, 94V-0 Flame Class Rating (3) |
2.3 |
mm |
UL 94 | |
|
Glow Wire Flammability Index 960°C, passes at |
1 |
mm |
IEC 60695-2-12 | |
|
Glow Wire Ignitability Temperature, 1.0 mm |
825 |
°C |
IEC 60695-2-13 | |
|
Oxygen Index (LOI) |
36 |
% |
ISO 4589 | |
|
UV-light, water exposure/immersion |
F2 |
- |
UL 746C | |
|
Processing |
| Parameter | ||
Injection Molding |
Value | Unit |
|
Drying Temperature |
120 |
°C |
|
Drying Time |
2 - 4 |
hrs |
|
Maximum Moisture Content |
0.02 |
% |
|
Melt Temperature |
290 - 320 |
°C |
|
Nozzle Temperature |
280 - 310 |
°C |
|
Front - Zone 3 Temperature |
290 - 320 |
°C |
|
Middle - Zone 2 Temperature |
280 - 310 |
°C |
|
Rear - Zone 1 Temperature |
270 - 300 |
°C |
|
Hopper Temperature |
60 - 80 |
°C |
|
Mold Temperature |
80 - 120 |
°C |
